4K (IXM179): UC80MPA

Name: 4K (IXM179): UC80MPA
SKU: UC80MPA
Availability: InStock

Price range: $79.00 through $89.00

Spinel 8MP Resolution with 1/3.2″ SONY IMX179 image sensor

MJPEG& YUV2 streaming, supports 3265×2448 up to 15fps

Lens

Clear

Image Device: 1/3.2’’ SONY IMX179
Pixel Size: 1.4μm x 1.4μm
Resolution: 8MP 3264(H) X 2448(V)
Output Format: MJPEG / YUV2（YUYV）
Shutter Type: Electronic rolling shutter
Focus: Manually adjustable
Focusing Range: 20mm to Infinity
Protocol & Connection: Plug-&-Play (UVC compliant)
Frame Rate: 3265×2448 MJPEG @15FPS
Minimum Illumination: 0.05 Lux
IR-Cut Filter (IR Filter): Default at 650nm built-in on sensor
Lens: 90 degree FOV non-distortion lens
Night Vision: Supported with use of white flash LED’s ONLY
IR Illumination: IR LED not supported, can customize with 12/24 pcs white flash LED plate upon request
Controllable Features: Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White balance, Backlight Contrast, Exposure
Power Socket: 4P PH 2.0mm socket, USB BUS Power
Cable Length: Default 1.2M(4ft) (others upon request)
Supported OS: Win XP/Vista/Win7/Win8/Win10; Linux with UVC (linux-2.6.26 or later); MAC-OS X 10.4.8 or later; Wince with UVC; Android 4.0 or higher with UVC
Power Consumption: DC5V (±5%), 140mA
Operating Temp.: -4°F~167°F (-20°C~+75°C)
Storage Temp.: -40°F~185°F (-40°C~+85°C)
Humidity: Less than 80%
Dimension: 38mmx 38mm
Weight: Approx. 12 Grams or 0.4 Ounce

Weight	6.00000000 oz
Lens	fisheye 1.0mm, fisheye 1.39mm, 2.1mm, 2.8mm, non-distortion 3.5mm, 4mm, non-distortion 4.2mm, 6mm, 8mm
